Ethernet: A Radio Station Installs Cablesys Pre-terminated Patch Panel System

Posted by Cablesys on Jan 13th 2023

New Hampshire – A radio station that provides audio and video production installed Cablesys Pre-terminated Patch Panel System. Their staff used the Patch Panel-to-Mobile Box model to run data connectivity from network racks to areas with no outlets. Cablesys helped build the materials.

Cablesys built ten Category 6 (CAT 6) mobile boxes with patch panels. A mobile box provides six Ethernet ports and is made with sturdy ABS plastic to withstand harsh environments. The process involved terminating 25 and 50-foot CAT 6 cables to mobile boxes on one end and CAT 6 keystone connectors on the other end. Bezels were applied allowing the connectors to snap into the patch panel. The cables were bundled and labeled to make routing and identification easy. All terminations were tested using a Fluke DSX8000 cable analyzer.

Once their personnel received the materials at the radio station, they screwed bracket panels onto network racks, snapped in the connectivity, routed the cables, and laid the boxes down.

To learn more, please visit: Pre-terminated Ethernet Patch Panel System

Related topics: How are Pre-terminated Patch Panels built?
